兩層恒溫恒濕試驗箱

產品已廣泛應用于科研,電工,電子,航天,航空,郵電通信,汽車,摩托車等企事業單位，提供按GB,IEC,DIN等標準相對應的技術參數制作各類可靠性環境試驗設備.

產品詳情

型號Model			ATH-080	ATH-100	ATH-150	ATH-225	ATH-408	ATH-800	ATH-1000
內箱尺寸Internal dimensions.W×H×D(cm)			40×50×40	40×50×50	50×60×50	50×75×60	60×85×80	100×100×80	100×100×100
外箱尺寸External dimensions.W×H×D(cm)			85×140×95	85×140×105	95×150×105	95×165×115	105×175×135	145×190×135	145×190×155
溫濕度范圍Temp.＆Humidity Range			0℃、-20℃、-40℃、-60℃、-70℃～+100℃（+150℃） 20%～ 98%RH
Performance 性能	溫濕度波動度Temp.＆Humi.Constancy		±0.2℃(C)、±0.3℃(B)；±2.5%RH(C)、±3.0%RH(B)
	溫濕度均勻度Temp.＆Humi.Uniformity		±0.5℃；±4.0%RH
	解析精度Indication Resolution		±0.01℃；±0.01%RH
	升溫Heat-up 時間Time(20℃～HT)	℃	100 150	100 150	100 150	100 150	100 150	100 150	100 150
		Min	30 40	30 45	30 40	30 45	30 45	30 45	30 45
	降溫Pull-down 時間Time(20℃～LT)	℃	0 -20 -40 -60 -70	0-20 -40 -60 -70	0 -20 -40 -60 -70	0-20 -40 -60 -70	0 -20 -40 -60 -70	0 -20 -40 -60 -70	0 -20 -40 -60 -70
		min	25 40 50 80 90	25 40 50 80 90	25 40 50 80 90	25 40 50 80 90	25 40 50 80 90	25 40 50 80 90	25 40 50 80 90
Material 材料	外箱材質External material		Stainless steel SUS#430 Plate+Powder coated
	內箱材質Internal material		SUS#304 stainless steel plate
	隔熱材質Thermal insulation material		PU＆Fiberglass wool
Systems 系統	循環系統Circulatory system		Siroco fan
	加熱系統Heating system		SUS#304 stainless steel high-speed heater
	加濕系統Humidification system		Surface evaporating system
	制冷系統Refrigeration system		Airtight compressor+evaporator fins+air-cooling condenser
	除濕系統Dehumidification system		ADP Critical dewpoint cooling/dehumidifying method
	控制系統Control system		Digital electronic indicators +S.S.R.with PID automatic calculation capabilty
附件Other Components			Vacuum glass inspection window,cable port(∮60mm),control status indicator lights. Chamber lamp,experiment separation shelves(freely adjustable 2pcs)
保護裝置Savety Devices			Overheating prevention circuit-breaker,compressor overload protection,control system overload protection, Humidifying system overheating drying out prevention,breakdown indicator light.
電源	Power Source		AC 1￠220V; 3￠220V/380V 60/50HZ
